Reinforcement PET Anti-crack geocomposite for road rehabilitation

Anti-crack geocomposite43.jpg



PET Anti-crack geocomposite is PET geogrid reinforcing geotextile,it’s a flexible, composite reinforcement grid comprising polyester grid combined with an ultra light nonwoven geotextile. Coated with bitumen, this composite creates a strong bond with asphalt that allows its tensile strength and distribute loads over a greater area. It’s the best solution for reflective cracking.
There is one significant enhancement compared to the regular geogrid products: the non-woven fabric layer is saturated with bitumen in order to provide an effective moisture barrier.



Feature
• High temperature resistance
• High installation safety through good bonding of the composite product with the substrata.
• Melting installation and ensures very good layer bonding.
• Long-term dynamic load-carrying capability
• High resistance to the mechanical damage
• High flexibility and adaptability simplify laying
• Resistant to installation damage

Type Item No. Tensile Strength Elongation Mesh Size Width
(kN/m)
MD CD (%) (mm*mm) (m)
PET  Anti-crack Geocomposite PGR5050 50 50 10 5-50 1–5
PGR8080 80 80 10 5-50 1–5
PGR100100 100 100 10 5-50 1–5
PGR120120 120 120 10 5-50 1–5
PGR150150 150 150 10 5-50 1–5
PGR200200 200 200 10 5-50 1–5
